Shenzhen Shengdian AOI optical inspection equipment (Automated Optical Inspection) of the operation process. 1:

1. Preparation: First of all, the operator needs to check the AOI optical inspection equipment to ensure that the equipment is in a normal state and the components are intact. At the same time, it is also necessary to prepare the circuit board or electronic components to be inspected, and select the appropriate inspection settings and programs according to the actual situation.

2. Load the workpiece: Before starting the equipment, the operator needs to place the circuit boards or electronic assemblies to be inspected onto the working table or conveyor belt of the equipment. Note that the position and placement of the workpiece should be in accordance with the requirements of the equipment to ensure the accuracy of the inspection results.

3. Start the equipment: when the preparatory work is completed, the operator in accordance with the equipment start-up process operation, the AOI optical inspection equipment connected to the power supply, and according to the equipment's operating manual to carry out the correct start-up steps. In general, the need to carry out the equipment's self-calibration and image adjustment and other work.

4. Setting inspection parameters: Once the equipment is successfully started, the operator needs to set the appropriate inspection parameters according to the characteristics and requirements of the workpiece to be inspected. This includes adjusting the light source, contrast, exposure time, focal length, etc., and can be set according to the need for specific detection algorithms or rules.

5. Start inspection: After completing the parameter settings, the operator can start the AOI optical inspection equipment to begin the inspection process. The equipment will capture the image of the workpiece at high speed and use the built-in image processing algorithm to analyze and compare. At the same time, the device will also record and display the inspection results for the operator's reference and record. SMT Equipment Factory

6. Analyze and process the results: After the inspection is completed, the operator needs to analyze and process the inspection results. On the one hand, you can observe the defective parts or defects of the workpiece through the display interface of the equipment and mark the records; on the other hand, you can also export the data to the computer for further statistics and analysis.

7. Adjustment of equipment and workpiece position: If problems or misjudgment are found during the inspection process, the operator can adjust the parameters of the equipment or the position of the workpiece according to the actual situation in order to improve the accuracy and stability.

8. end of work: when all the workpieces to be detected by the AOI optical inspection equipment, the operator can turn off the equipment and clean up the work area. At the same time, it is also necessary to carry out routine maintenance and repair of the equipment to ensure the normal operation and prolong the service life of the equipment.

The above is the operation process of AOI optical inspection equipment of Shenzhen Shengdian Electronic Equipment Co.
