Brief:SMT ovens are core equipment in surface mount technology, with key features including precise temperature control, efficient production, and process adaptability: Core Features Precise Temperature Control System Utilises an intelligent PID control system or microcomputer temperature controller, achieving temperature control accuracy of ±2°C to ensure uniform and stable temperatures inside the oven and prevent local overheating that could damage components. The preheating zone to the reflow zone employs multi-zone independent temperature control (typically 4–10 zones), supporting stepwise temperature ramp-up curves to meet the thermal sensitivity requirements of different PCB materials and components. Infrared heating technology combined with a hot air circulation system ensures an internal temperature difference of ≤5℃, eliminating soldering defects caused by the ‘shadow effect.’ Efficient production and automation Integrated automated conveyor chain (±10 mm/min precision) supports online connection with pick-and-place machines, enabling continuous production. Rapid heating design (reaches operating temperature in 10-15 minutes) reduces power consumption by 30%-40% compared to traditional equipment. Equipped with SPI online detection functionality, real-time adjustment of process parameters achieves a yield rate of over 99.8%.
Brief:PCB Curing Oven with Instrument Panel are primarily used for automated soldering of through-hole components to circuit boards. Their core functions and technical advantages are as follows: Core Functions High-efficiency batch soldering By immersing the entire PCB board with through-hole components into molten tin (250–280°C), all through-hole solder joints are completed in a single process, significantly improving production efficiency. This is particularly suitable for through-hole processes and SMT red glue surface soldering. Ensuring Solder Joint Reliability Precise control of immersion depth (1/2–2/3 of PCB thickness) and angle (5–10°) ensures full solder filling of through-holes, achieving 100% solder penetration and eliminating missed or incomplete solder joints. Solder joints are full and smooth, with high mechanical strength and excellent vibration and crack resistance, meeting the demands of high-reliability fields such as medical and automotive electronics. Compatible with complex PCB designs Suitable for single/double-sided, multi-layer high-density circuit boards, with unique advantages for densely laid-out or large pad through-hole components (such as transformers and connectors).
Brief:As an experimental-grade reflow soldering equipment, the Desktop Reflow Oven machine has the following core features and functions: Core Features Compact Modular Design Adopting a drawer-type structure, it has a desktop-sized volume that saves space, is easy to maintain, and supports non-standard customisation. Precise Temperature Control Technology Independent temperature zone control (±2°C accuracy), with a maximum temperature difference of 100°C between adjacent zones without temperature crossover. Infrared uniform heating combined with an independent small-cycle air circulation system, enabling rapid thermal compensation (temperature difference <5°C). High-performance configuration Patented heating wire technology achieves rapid heating in 20 minutes, reducing energy consumption by 30%. Optional forced cooling and flux recovery systems are available to meet environmental requirements.
Brief:Vacuum reflow soldering, as an advanced soldering technology, plays a crucial role in multiple aspects: Prevents oxidation of solder joints, ensuring robust and reliable soldering, and enhancing overall soldering quality. Utilises vacuum pressure differences to remove bubbles from molten solder, significantly reducing porosity (to below 10%, and as low as 3–5% under optimal conditions), thereby improving the density and purity of solder joints. Improving the electrical conductivity, thermal conductivity, mechanical strength, sealing performance, and pressure resistance of solder joints, thereby enhancing device reliability. Reducing soldering defects (such as porosity or impurities), preventing damage to chips and substrates, and improving product yield. Enabling flux-free soldering, reducing environmental pollution and environmental protection costs. Minimising thermal stress through precise temperature control (such as infrared uniform heating), ensuring uniform solder melting and avoiding overheating issues. Easy to operate and learn, improving production efficiency and adapting to diverse application scenarios (such as high-density packaging of chip capacitors, inductors, etc.) Widely applied in high-reliability fields such as aerospace, military electronics, medical devices, and automotive electronics, meeting stringent quality requirements
Brief:The mini reflow soldering machine (also known as desktop reflow soldering) is a compact soldering device designed for R&D, small-batch production, and special scenarios. Its core function is to meet specific soldering needs at low cost and with flexible operation, complementing traditional large multi-zone reflow soldering machines. Core Functions and Positioning Differences R&D Validation and Small-Scale Production Suitable for new product prototype testing and process parameter tuning (e.g., lead-free solder experiments), avoiding the use of large-scale production line resources and significantly reducing R&D costs. Repair and Rework Support Enables localised rework on individual PCBs, precisely controlling the soldering position (e.g., BGA chip rework), avoiding secondary damage caused by re-flowing the entire board. Educational and Training Tools Used in electronics-related academic institutions to demonstrate the entire SMT reflow soldering process (preheating → reflow → cooling), providing an intuitive demonstration of solder joint formation mechanisms.
Brief:1. It adopts LCD computer + Intelligent Siemens control system and adopts modular temperature control system with high precision of ± 1 °C (if the computer crashes accidentally, it can work offline without affecting production) , which guarantees the stability and reliability of the Control System; 2. Windows 7 operating interface, powerful, easy to operate, and with a key reduction system; 3. The upper furnace body is opened with a double cylinder jacking machine to ensure safety and reliability 4. Equipped with net belt tension device, smooth transportation, no jitter, no distortion, to ensure smooth PCB transportation; 5. The transmission mechanism of synchronous Guide Rail (can connect with automatic mounter on-line) to ensure accurate width adjustment of guide rail, High Service Life and anti-button curve; 6. Manual control lubrication system, refueling time manually controlled by the amount of oil, lubrication transmission chain; 7. All heating areas are PID controlled by computer (can be divided into separate temperature areas opened separately. Can Be divided to reduce the starting power, heating time 10-15 minutes) ; 8. The network/chain transmission is controlled by computer in full closed loop, which can meet the needs of different kinds of PCB production 9. Has the breakdown sound and light alarm function (uses the LED lamp) ; 10. It adopts the world-leading hot air circulation heating mode of Heller, high-efficiency pressurization type accelerating air duct, greatly improves the circulation hot air flow rate, raises the temperature quickly, has high thermal compensation efficiency, can carry on the high temperature welding and curing; 11. Temperature zone is equipped with independent temperature sensor, real-time monitoring and compensation of the temperature balance of the temperature zone; 12. Have Password Management of the operating system, to prevent unrelated personnel change process parameters, operation records management traceable process parameters change, easy to improve management. The utility model can store the user's existing temperature speed setting and the temperature curve under the setting, and can print all the data and the curve; 13. Integrated Control Window, computer switch, test curve, print curve and transfer data are easy to operate, design humanization. Equipped with three-channel temperature curve on-line testing system, it can test the actual temperature curve of the welding object at any time (without additional temperature curve Tester) ; 14. Specially designed pressurized air transport structure and shaped heating wire design, no noise, no vibration, with high heat exchange rate, the temperature difference △t between BGA bottom and PCB board is extremely small, most in line with the strict requirements of lead-free process, especially for high-difficulty welding requirements of lead-free products.
Brief:1. It adopts LCD computer + Intelligent Siemens control system and adopts modular temperature control system with high precision of ± 1 °C (if the computer crashes accidentally, it can work offline without affecting production) , which guarantees the stability and reliability of the Control System; 2. Windows 7 operating interface, powerful, easy to operate, and with a key reduction system; 3. The upper furnace body is opened with a double cylinder jacking machine to ensure safety and reliability
