Automatic Pick and Place Machine

Basic Concept of SMT (Surface Mount Technology) Machine

SMT (Surface Mount Technology) Automatic Pick and Place Machine is a key equipment in the field of electronic manufacturing, used to realize the surface mount technology. This equipment is able to accurately install electronic components on PCB (Printed Circuit Board) to complete the assembly process of electronic products. Automatic Pick and Place Machine is usually characterized by high precision, high speed and high efficiency, which can meet the needs of modern electronic product production.

The Main Types of SMT Automatic Mounter

According to the function and structure characteristics, SMT automatic mounter is mainly divided into several types such as high-speed mounter, multifunctional mounter and modular mounter. High-speed mounter is suitable for mounting a large number of low-complexity components, while multifunctional mounter has high mounting accuracy and flexibility, and is suitable for mounting various types and sizes of components. Modular mounter is a kind of expandable mounter system, realizing different functions and performance through different module combinations, with high production flexibility.

The Working Principle of SMT Automatic Pick and Place Machine

The working principle of SMT Automatic Pick and Place Machine involves a combination of machine-electrical-optical and computer control system technologies. The placement head is an intelligent robot equipped with multiple suction nozzles capable of picking up and placing components precisely. The suction nozzles directly pick up SMD (Surface Mounted Device) components through negative vacuum pressure and are programmed to be responsible for picking up the specified components through a motor and camera-recognition control system loaded on the placement head. The automatic mounter completes the production of SMD processing through the cooperation of each component, and mounts various types and sizes of SMDs to the designated pad locations on the circuit board.
