Looking for a reliable, efficient conveyor solution to streamline your DIP production line? Look no further than the SHENGDIAN SD-1500DIP Guide Rail Exit Conveyor—engineered by Shenzhen Shengdian Electronic Equipment Co., Ltd. to redefine stability, flexibility, and productivity in electronics manufacturing.
Crafted with a robust frame of sheet metal and 40*40 iron square tube welding, finished with a high-quality baking paint, this conveyor boasts exceptional sturdiness and durability, standing up to the rigors of non-stop factory operations. Its three-section transmission design—featuring parallel, slope, and parallel segments—ensures smooth board transfer, eliminating jams and ensuring consistent workflow. Equipped with three 15W speed-regulating motors (each independently controlling a section) and anti-slip silicone chains, it delivers stable, adjustable speed from 0 to 1500mm/min, adapting seamlessly to your production rhythm.
Precision and versatility are at its core. The custom aluminum machined guide rails allow easy width adjustment from 50mm to 350mm, accommodating various board sizes with minimal effort. Imported STK bearings and metal transmission wheels guarantee smooth, low-noise operation, while the 20mm standard lead screws and nuts enable precise height adjustment—900-1200±50mm for the inlet and 750-900±50mm for the outlet—aligning perfectly with your existing production line.
Designed for efficiency, it can hold up to 3 boards and comes standard with SMEMA communication signal lines, enabling seamless integration with other equipment. Five sensors and three control cards ensure accurate positioning and reliable operation, while a set of six axial cooling fans prevents overheating, safeguarding both the machine and your products. With a power consumption of just 100W and a total power of 200W (220V 50/60Hz), it balances performance with energy efficiency.
Whether your transmission direction is left-to-right or right-to-left (customizable), the SD-1500DIP adapts to your layout. It’s the ideal addition to DIP lines, enhancing throughput without compromising quality. Trust SHENGDIAN’s expertise in electronic equipment—this conveyor is built to boost your productivity, reduce downtime, and support your long-term manufacturing success. Upgrade your production line today with the SD-1500DIP Guide Rail Exit Conveyor!
