1. Preliminary preparation

1. Ensure that the device is working properly: Before operating the SMT First Article Inspection Machine, ensure that the device is working properly. Check whether the power cables, sensors, and control panel are normal.

2. Clean the test platform: Remove any residue and impurities on the test platform to ensure that the platform is clean and tidy, and ensure that the product is not affected by external factors during testing.

3. Prepare the product for testing: Pick up the first product from the production line to ensure that it meets the design requirements and product specifications.

Second, initialize the equipment -SMT equipment factory

1. Turn on the power switch: Press the power button and enter the standby state after the device is started.

2. Select the test mode: Select the corresponding test mode and parameters on the control panel according to the product test requirements.

3. Set the test conditions: according to the product characteristics and specifications, set the appropriate test conditions on the control panel, such as current, voltage, color, etc.

3. Start testing

1. Positioning the product: accurately position the product to be tested on the test platform, and ensure that the pin of the product is fully in contact with the test interface.

2. Start the test: press the start button, and the first SMT tester starts to test the product. It may be accompanied by some sound and light cues.

3. Observe the test results: Observe the digital display on the control panel and the indicator light of the device itself to understand the test results.

4. Processing test results

1. Qualified product: If the test result is normal, "PASS" or "Qualified" will be displayed on the control panel, and the product can continue to be produced.

2. Unqualified product: If the test result is abnormal, "FAIL" or "Failed" will be displayed on the control panel. In this case, you need to handle it accordingly.

3. Fault analysis: According to the test results and equipment alarm information, fault analysis is carried out to find the cause of nonconformity.

4. Deal with unqualified products: For unqualified products, you can repair, replace parts or re-test until the test is qualified.

End the operation

1. Disconnect the power supply: After the test is completed, press the stop button and then turn off the power switch.

2. Clean the test platform: Remove any residue and impurities on the test platform to ensure that the equipment is clean and properly stored.

3. Record data: Record the data, test results and corresponding operations of each test for future reference and analysis.

Conclusion: SMT First Article Inspection Machine is an important tool to ensure the quality of circuit board pipeline products. Proper operation and use of this SMT equipment is critical to ensuring product quality. Through the above operation methods, you will be able to accurately and efficiently use the SMT First Article Inspection Machine, improve product quality, and bring higher benefits to your production line. SMT equipment factory
