Operation Flow of Wave Solder Out-Feed Conveyor

Wave Solder Out-Feed Conveyor is a kind of soldering equipment commonly used in the electronic manufacturing industry for fixing electronic components on circuit boards. The following is the operating procedure of wave soldering machine:

1. Preparation: First of all, the operator needs to check whether the various components of the wave soldering machine is intact, to ensure that the equipment is in normal working condition. At the same time, you need to prepare the circuit board to be welded and the corresponding welding materials, such as solder, etc. 2.

2. Set welding parameters: According to the actual demand, the operator needs to set the appropriate welding parameters according to the requirements of the circuit board and welding materials. This includes soldering temperature, speed, wave height, preheating time and so on. Generally, the parameters can be adjusted and set through the control panel or software of the equipment.

3. Load the circuit board: After setting the welding parameters, place the circuit board to be welded onto the working table of the wave soldering machine. Make sure that the board is in the correct position and that there are no other obstacles in the welding area.

4. Start the equipment: After completing the placement of the circuit boards, the operator follows the startup procedure of the equipment, turns the wave soldering machine on and performs the correct startup steps according to the requirements. This process may include operations such as self-testing, calibrating and warming up the equipment.

5. Start welding: When the wave soldering machine reaches the preset welding temperature and state, the operator can start the actual welding operation. The equipment will send the preheated wave of solder to the welding area, and the components on the board will contact with the solder and finish welding.

6. Checking the quality of the soldering: After the soldering is completed, the operator needs to check the quality of the soldering. You can use visual or microscope to observe whether the solder joints are full, whether the welding is uniform, but also need to check whether the welding of cold welding, bias welding and other issues.

7. Correction of defective solder joints: If the inspection process found that there are bad solder joints, the operator needs to correct the operation. You can use the soldering iron to make up the welding, or by resetting the welding parameters and adjusting the welding position to improve the welding quality.

8. Completion of the work: When all the welding work is completed, the operator needs to turn off the wave soldering out of the board machine, and equipment cleaning and maintenance work. At the same time, it is also necessary to clean up the welding area and waste in a timely manner, and properly dispose of the used welding materials.

The above is the operation process of Wave Solder Out-Feed Conveyor. In the operation process, the operator needs to strictly comply with the operating procedures and safety requirements of the equipment, maintain concentration, and always pay attention to the welding quality. In addition, regular maintenance of the equipment can ensure the stability and long service life of the wave soldering machine.
