Operation flow of board loading machine feeder-SMT equipment factory

PCB loading machine is a kind of automation equipment, which is used to press-fit the completed PCB boards to the substrate and ensure accurate positioning and reliable connection. In this article, I will introduce you to the operation process of PCB board loading machine.

1. Preparation:

  a. Ensure that the PCB board and substrate have been completed and checked through.

  b. Prepare the required components, solder paste and other auxiliary materials, and ensure that they are of good quality.

  c. Clean and organize the work area to ensure that the work area is dust-free and tidy.

2. Adjust the board loading machine:

  a. Adjust board loading machine fixtures and guides according to PCB board and substrate dimensions and requirements.

  b. According to the thickness and requirements of the PCB board, set the appropriate pressure and speed.

3. Prepare the PCB board:

  a. Place the PCB board on the carrier frame and adjust the clamping mechanism to ensure the alignment and overlap between the PCB board and the substrate.

  b. Inspect the PCB board for any damage, scratches or dirt and clean and dispose of it promptly.

4. Prepare the substrate:

  a. Place the substrate on the table of the board loading machine and adjust the clamping mechanism for alignment and overlap with the PCB.

  b. Check the substrate for any damage, scratches or dirt and clean up and dispose of them in time.

5. Board loading operation:

  a. Select the appropriate program and parameter settings through the control interface of the board loading machine.

  b. Place the PCB board and the substrate in the working area of the board loading machine to ensure that they are correctly aligned.

  c. Start the board loading machine to begin the automatic board loading operation. The board loading machine will accurately press the PCB board onto the substrate according to the set program.

6. Soldering:

  a. After completing PCB loading, transfer the substrate to the soldering equipment for subsequent soldering operations.

  b. Soldering is performed according to specific needs, either by manual soldering or automated soldering equipment.

7. Inspection and Repair:

  a. Check the connection between the completed PCB and the substrate to ensure that the solder joints are complete and there are no short circuits or other problems.

  b. If any problems are found, repair and adjust promptly.

8. Testing and Acceptance:

  a. After soldering, conduct a thorough electrical test and appearance inspection to ensure that the PCB and substrate are connected and functioning properly.

  b. Check to see if it meets the specifications and requirements, and if there are defective items, then it needs to be repaired and tested again.SMT Equipment Factory
