PCB Pick and Place Machine style and use tips for SMT equipment

In the market, there are two common PCB Pick and Place Machine styles: manual and automatic Pick and Place Machine. A manual Pick and Place Machine requires an operator to manually place components in place and then attach them to a printed circuit board via a robotic arm. In contrast, automatic Pick and Place machines have a higher degree of automation and can automatically complete the installation of components according to preset procedures. SMT equipment factory

When operating a PCB Pick and Place Machine, you first need to prepare the required components and printed circuit boards. Place the printed circuit board on the workbench of the machine and adjust the position to ensure its accuracy. Then, according to the set process parameters, select the appropriate sticker head. The selection of the sticker head should be determined according to the size and shape of the component to ensure accurate mounting. Next, the component is placed on the patch head, usually with the help of a vacuum suction cup.

When everything is ready, you can start running the machine. In the domestic SMT machine, by inputting the corresponding program instructions, the machine can automatically mount the components. On a manual patch machine, the operator needs to manually control the robotic arm to attach the components to the printed circuit board. SMT equipment factory

Whether it is manual or automatic style, some details need to be paid attention to during use. First of all, make sure that the component matches the circuit board and the size meets the requirements. Secondly, it is necessary to control the contact force between the sticker head and the printed circuit board to avoid excessive pressure on the circuit board. In addition, pay attention to the temperature of the sticker head to avoid overheating damage to the components.

When all components are installed, the PCB Pick and Place Machine will self-test to confirm whether the installation effect meets the requirements. If there is a problem, it needs to be adjusted and repaired in time. Finally, the printed circuit board of the attached component is sent to the next process to complete the entire patch work. SMT equipment factory
