I. Principle of Shengdian SMT equipment oven

The working principle of SMT oven is based on the heating and cooling process of circuit board by hot air. It melts and solidifies the solder paste by controlling the temperature and time to complete the bonding and connection between electronic components and circuit boards.SMT equipment factory

Second, the style of SMT oven

1. Infrared type: using infrared radiation heating to reach high temperature in a short time. Suitable for small batch production.

2. Convection type: Conduct heat through the circulation of hot air, uniform and stable heating. Suitable for large-scale mass production.

3. Nitrogen type: use nitrogen environment in the sintering process to reduce the effect of oxygen on the solder joints and improve the quality of solder joints.

4. Lead-tin wave type: Used in wave soldering process, the solder material is coated on the circuit board pad through liquid lead-tin wave.

Third, the characteristics of Shengdian SMT oven

1. Precise temperature control: the temperature can be monitored and adjusted in real time by the advanced temperature control system to ensure the stability and reliability of the welding quality.

2. Uniform heating: the product is equipped with fans and heating elements, which can maintain the uniform distribution of hot air, so that the temperature distribution in the welding process is uniform.

3. High production efficiency: adopting automatic control technology, it can realize continuous operation, efficient operation and improve production efficiency.

4. environmental protection and energy saving: the use of heating elements are usually energy efficient way to reduce energy consumption, reduce the impact on the environment.SMT equipment factory

Fourth, the importance of SMT reflow oven equipment in the electronics manufacturing industry

SMT oven plays a vital role in the electronics manufacturing process, has the following important role:

1. Improve soldering quality: through precise temperature control and heating uniformity, to ensure reliable connection between the soldering point and the circuit board, reduce soldering defects.

2. Increase production efficiency: automated operating system, continuous operation mode and efficient heat treatment technology can significantly increase production efficiency.

3. Adapt to diversified production needs: good adaptability to meet the welding needs of electronic components of different sizes and shapes.

4. Reduce costs: efficient working mode, stable quality control and energy saving features, can reduce production costs.

SMT oven is an indispensable equipment in the electronic manufacturing industry, through its precise temperature control and efficient heating technology, it can improve the welding quality, increase the production efficiency, and meet the diversified production needs.SMT equipment factory
