The structure and advantages of Shuttle Conveying Machine of SMT equipment factory

SMT Shuttle Conveying Machine is mainly used to carry components from the flyer to the printed circuit board (PCB), and it can also be realized to carry components from the PCB to the next process. In the electronic production line, the transfer machine not only improves the production efficiency, but also greatly reduces the risk of error when manually carrying components.

Shengdian SMT Shuttle Conveying Machine usually consists of the following parts: body, transfer system, clamping system and so on. Among them, the body is the main part of the whole equipment, responsible for supporting and fixing the components such as the transfer system; the transfer system includes the conveyor belt and rollers, etc., which transfer the components from the flyer or PCB to the next process; the clamping system is used for clamping the components to avoid problems such as dislodging them during the transfer process.

According to the structural form of the transfer machine, SMT Parallel Shuttle Conveying Machine can be divided into two types: platform type and sliding table type. The former refers to the PCB on a platform, and then through the machine arm or conveyor line to move the PCB to other positions. The latter is to move the PCB from one position to another through a sliding table, which is suitable for production lines that require a large number of repetitive operations.SMT Equipment Factory

Secondly, according to the degree of automation, SMT Parallel Shuttle Conveying Machine can be categorized into fully automatic, semi-automatic and manual. Fully automatic can complete the entire PCB printing process, including spraying tin, patch, welding, etc., high efficiency but also higher cost. Semi-automatic requires manual assistance to place or take away the PCB, applicable to the production line production is low. Manual is completely dependent on human movement PCB, suitable for small-scale laboratory research or sample production.

Third, according to the scope of application, SMT Shuttle Conveyor with Single Cart can be divided into single-sided, double-sided and multilayer boards. Single-sided can only handle single-sided PCBs, double-sided can handle two-sided PCBs at the same time, while multilayer boards can handle the production of multi-layer PCBs.

Finally, with the development of intelligent manufacturing, some new types of SMT Shuttle Conveyor with Single Cart are beginning to appear. For example, styles equipped with artificial intelligence algorithms have improved production efficiency; new products equipped with tracking systems have reduced production accidents caused by operational errors.
