Styles and Sizes of Shuttle Conveyor with Single Cart

Shuttle Conveyor with Single Cart is a common automation equipment, which is mainly used for assembling and conveying circuit boards in electronic production lines. It can move the assembled circuit boards from one workstation to another to ensure the smooth and efficient flow of the production line.

Parallel Shuttle Conveying Machine This kind of SMT equipment is available in various styles and sizes, so you can choose the right model according to different needs and application scenarios. Shengdian SMT equipment factory will introduce several common styles and sizes below:

Single layer: it is the simplest and commonest style, which consists of a fixed platform and several sliding tables. The size is usually 1000mm×500mm, which is suitable for small scale production line. Double Deck: A second platform is added to the single deck transfer machine, allowing two circuit boards to be moved at the same time. The size is usually 1000mm x 1000mm and is suitable for medium-sized production lines. Linear Transfer: Also known as the parallel style, it consists of multiple platforms connected in series and can be adjusted in length as needed. It can handle multiple circuit boards at the same time and is capable of continuous conveyance. The size can be customized according to actual needs. Rotary transfer: Adopting a rotary mechanism, it can transfer circuit boards from one workstation to another. The size is usually 800mm×800mm, which is suitable for production lines that require rotary operation. Shengdian SMT equipment factory

In addition to the above common styles and sizes, there are also some special customized circuit board Parallel Shuttle Conveying Machine for selection. When choosing the right model, you need to take into account the product specifications, the space layout of the production line, production efficiency and other factors. The SMT Shuttle Conveying Machine produced by Shenzhen Shengdian Electronic Equipment has the following styles and sizes: single-car shifting machine and multi-car shifting machine, which is characterized by the use of Panasonic PLC, Omron original photoelectricity, LEF intermediate relay control system, stable and reliable work. Touch screen display operation with fault sound and light alarm and automatic diagnostic function. Stepping motor control, speed and distance adjustable. Imported steel belt drive, accurate positioning, durable. Adopting Taiwan Shangyin linear slide rail, with good sliding, durability and positioning accuracy. A variety of modes are available to meet a variety of production processes, easy to operate. Conveying height of 900 mm ± 30Used power: ± Single phase 220V 50/60HZ 100W.Enclosed design ensures the highest level of safetyTop safety cover can be opened for easy handling of machine hardware during maintenanceEasy-to-use touch screen functionControl interfaceRobust balanced width adjustment (hand cranked control screw adjustments)Conveying distance can be arbitrarily set. Compatible with SMEMA interface.
