Features
1. Design of sheet metal dusting structure
2. Increase the design to improve stability
3. In line with the ergonomic design concept, so that the operator's arm is not easy to fatigue
4. High-precision screw adjustment wide and narrow, to ensure that the transport rails are parallel
5. According to customer requirements to customize the length of the machine
6. According to customer requirements, the number of stop plates
7. The transmission speed can be adjusted
8. Using professional wear-resistant anti-static flat belt,
9. Special electrophoresis aluminum profile rail
10. Work surface anti-static rubber to better prevent static electricity
11. Transfer motor with double stepper motor
12. Compatible with standard SMEMA interface
Technical parameters
Model | SD-500 | SD-1000 | SD-1200 |
Outline dimensions（mm） | 500*670*900 | 1000*700*900 | 1200*700*900 |
Table size（mm） | 400*200mm | 800*200mm | 800*200mm |
PCB width | 50-350mm (Can be customized) |
Transport height | 900±20mm |
PCB transport direction | L-R (R-L） |
PCB transport velocity | 0~2000mm |
Power supply | AC220V1P 50/60Hz |
Power consumption | Approx.30W |
Track length (Can be customized) | 500mm | 1000mm | 1200mm |
Control mode | PLC card |
Weight | About 35KG | About 50KG |
Single rail | Front fixed side, rear active side (optional rear fixed) |
