Brief:Product features：Exterior structure: plate gold structure and aluminum profile into the frame, the surface spray treatment and the color is wavy white.Microcomputer PLC control system works stably and reliably.Operating by touch screen, with automatic fault diagnosis function, convenient man-machine dialogue. Multiple sound and light and touch screen inside prompt alarm function.Using stepper motor to transmission.The bad board can be stored 10 pcs by rising and the good boards can be directly transported to the next machine.Applicable behind AOI and SPI devices.Double line number to distinguish NG\OK.
Brief:The SD-825L/833L/839L SMT board PCB loader is mainly used in the front part of the SMT production line, which can transport the PCB board to the following automatic solder paste printing machine, SMT pick and place machine and some other equipment sets. It has the function of automatic board loading which can save labor cost, improve production efficiency and increase yield of products.
Brief:The SD-825/833/839 SMT board PCB loader is mainly used in the front part of the SMT production line, which can transport the PCB board to the following automatic solder paste printing machine, SMT pick and place machine and some other equipment sets. It has the function of automatic board loading which can save labor cost, improve production efficiency and increase yield of products.
Brief:SD-825S/833S/839S SMT board Automatic PCB Unloader is mainly used in the back of SMT production line to retrieve PCB boards from automatic solder printing machine, SMT pick and place machine and other equipment groups into the Magazine. It has the function of automatic board retrieval, which can save labor cost, improve production efficiency and increase product output.
Brief:The SD-825/833/839 SMT board PCB loader is mainly used in the front part of the SMT production line, which can transport the PCB board to the following automatic solder paste printing machine, SMT pick and place machine and some other equipment sets. It has the function of automatic board loading which can save labor cost, improve production efficiency and increase yield of products.
Brief:1.Outer structure: plate gold structure, surface spraying treatment, color white.2.Microcomputer PLC and touch screen control system, stable and reliable work. 3.With automatic fault diagnosis function, man-machine dialogue is convenient.4.Multiple sound and light and touch screen within the prompt alarm function.
This equipment is used for SMT production line two in one or a diversion into two. Two-In-One-Out can save labor costs and save reflow soldering costs and electricity. One-In-Two-Out can save labor and equipment costs, this machine is used for two or more machines between the staggered panning, will be the PCB board panning to the next machine to continue to produce (suitable for Panasonic, Fuji (FUJI), YAMAHA, Samsung, Siemens dual-track mounter One-In-Two-Out and Two-In-One-Out).Using Panasonic PLC, Panasonic photoelectric CX442, YIJIA intermediate relay control system, stable and reliable work.Touch screen display operation, with the function of fault sound and light alarm and automatic diagnosis.Stepper motor control, speed, distance is adjustable.Using the imported belt steel wire belt drive, accurate positioning, durable.Using Taiwan upper silver linear slide rail, good sliding, durable, accurate positioning.A variety of modes are available for choice, to meet a variety of production process, simple operation, convenient.Translation single trolley drive: step drive + step motorTrolley rail transmission ordinary speed regulating motor transmission.The top safety cover can be opened to facilitate the processing of the machine hardware during maintenance.Width adjustment device for stable balance (hand control wire rod adjustment)The translation distance can be set at will.Compatible with a standard SMEMA interface.
Brief:Features: 1.This equipment is used for SMT. This equipment is used for the production line 90 degree lifting corner entry and exit board operation, two in one or one split into two. 2.Easy to use intelligent touch screen function control interface. 3.Adjustable corner speed ensures that the PCB board does not slide. 4.Width adjustment device for stable balance (hand control wire rod adjustment). 5.Smaller machine footprint. 6.Compatible SMEMA interface.
